QA: Twinkly Lights ON / OFF


Question

11 answers to this question

Recommended Posts

  • 0

@BodyartSir, thnx, I am not near my PC and can't see file via Sank.

I hope this VD for HC2 can works with latest FW (as i can see developers add auth and remove some functions for example switching effects)

Link to post
Share on other sites
  • 0

Hi @10der,



I used unofficial Twinkly API published here: https://xled-docs.readthedocs.io/en/latest/index.html  and it was last updated in 2018. It is still working with latest Twinkly firmware v2.5.6



I used RestAPI that is working on local network. Didn't want to use MQTT for which I expect that is changed after the last unofficial API.



Link to post
Share on other sites
  • 0
25 minutes ago, Sankotronic said:

Hi @10der,



I used unofficial Twinkly API published here: https://xled-docs.readthedocs.io/en/latest/index.html  and it was last updated in 2018. It is still working with latest Twinkly firmware v2.5.6



I used RestAPI that is working on local network. Didn't want to use MQTT for which I expect that is changed after the last unofficial API.





tnx for answer. I am using rest APi too.

but is not clear how to send effect with for example

Fireworks

:(









Link to post
Share on other sites
  • 0

Ukraine flag (HC3 lua develop)








Edited by 10der
Link to post
Share on other sites
  • 0
27 minutes ago, 10der said:



tnx for answer. I am using rest APi too.

but is not clear how to send effect with for example

Fireworks

:(



I know it is possible with MQTT to send name of the one of default effects. With RestAPI I still didn't find that possibility. For now this is what I tested and find working:



Changing LED operation mode payload sent to endpoint "/xled/v1/led/mode":

  • {"mode":"off"}
  • {"mode":"movie"} - starts last movie that was set with mobile app
  • {"mode":"effect"} - starts last default effect that was last played e.g. by demo (not mentioned in API reference)
  • {"mode":"demo"} - starts demo rotating through default effects
  • {"mode":"rt"} - real time movie need to send frames in real time

Changing LED brightness by sending payload to endpoint "/xled/v1/led/out/brightness":

  • {"value":brightness} where brightness is integer value 0 to 100 where 0 is also turning off LED (wrongly shows value sent as string {"mode":"enabled","type": "A","value": "100"})

And of course it is possible to send complete effect by uploading frames as you just demonstrated in previous post :-)



Edited by Sankotronic
  • Like 1
Link to post
Share on other sites
  • 0

tnx.

all function already was impemented.

i with to know how to switch to predefined effect. answer no how.

it's ok.



thank you very much



code for hc3 playing (local debugging by @jgabtools



attached



Twinkly.LUA

Edited by 10der
  • Thanks 1
Link to post
Share on other sites
  • 0

I think there is also {"mode": "playlist"}

I haven't checked it but such mode is displayed when I turn on playlist on Twinkly mobile app.

Link to post
